Flow Meter PNG Asset Pack: High-Quality Transparent Graphics for SCADA and HMI Layout Design
Quick Answer: This asset pack gives you transparent flow meter PNG files for SCADA screens, HMI mimics, and control system drawings. You can use the graphics for electromagnetic, Coriolis, ultrasonic, vortex, oval gear, and thermal mass flow meters without white background boxes. Silver Automation Instruments supplies the matching instruments and can prepare a PNG set based on your model list.
Most engineers skip one step when building a HMI layout. They drop a JPEG from a product catalogue onto a dark gray screen. The result is a white rectangle behind a 40 mm flow meter body. It looks wrong. This asset pack solves that problem with true alpha channel PNG files sized for common SCADA packages.
We have seen this on customer sites many times. A water treatment contractor in Malaysia needed a clean electromagnetic flow meter symbol for a remote terminal unit screen. A palm oil plant in Indonesia asked for a Coriolis meter graphic that could sit over a pipe line without hiding the pipe colour. Last year a customer in Vietnam asked us for a sanitary flow meter graphic for a pasteurizer HMI. These are the jobs behind this asset pack.
What Is in the Flow Meter PNG Asset Pack
The pack contains 86 transparent PNG graphics. Each file is saved at 300 dpi with an alpha channel. Standard sizes are 64 by 64 px, 128 by 128 px, 256 by 256 px, and 512 by 512 px. You can scale the 256 px and 512 px files up or down inside Ignition, Wonderware, FactoryTalk View, WinCC, VTScada, or Citect without losing edge clarity.
Files are named by meter type and size. Example names include electromagnetic_flow_meter_DN50_128.png, coriolis_mass_flow_meter_DN25_256.png, and vortex_flow_meter_DN80_256.png. The set includes top view and side view symbols. Line art versions use light gray and dark gray stroke colours. Flat colour versions use blue, green, red, and white fills. This naming style makes it easy to search inside a SCADA library.
The PNG pack is not just decoration. It works as a base layer for dynamic process values. You can place a live kg/h or m3/h value next to the symbol. The transparent background lets the value stay readable on light and dark HMI pages. That matters when an operator checks a brine line at 2:00 am.
Which Flow Meter Types Are Covered
The graphics cover six main flow meter types from the Silver Automation Instruments range. Electromagnetic flow meters are shown with flanged and wafer bodies from DN15 to DN300. They fit water lines with conductivity values from 5 µS/cm upward. For hazardous dosing skids, the symbol set includes an ATEX Zone 1 tag option. An electromagnetic meter may accept a PT100 temperature input and send a 4-20 mA HART signal to the control system.
Coriolis mass flow meters are shown with twin curved tubes and straight tube forms for liquid mass flow and density loops. A typical Coriolis application may handle syrup at 900 cP, 35 degrees Celsius, and 8,000 kg/h. The PNG symbol remains simple, so the HMI stays readable. Ultrasonic flow meters include clamp-on and inline symbols for water and seawater lines. Vortex flow meters are drawn for steam, compressed air, and hot water applications. A steam line may run at 12 bar and 190 °C. Oval gear flow meters are included for diesel, fuel oil, and batch loading. Thermal mass flow meters cover compressed air and biogas lines.
Why Transparent PNG Files Beat JPEG and White Background Symbols
A JPEG has no alpha channel. When you drop it onto a HMI screen, the background stays as a solid block. This block hides pipe colours, tank outlines, and valve states. A transparent PNG removes that problem. You see only the meter body, flanges, and connection lines.
But there is another reason. HMI layout design is not just about pretty screens. Operators use these screens to spot a flow drop from 14,500 kg/h to 9,200 kg/h in a chemical feed line
SCADA and HMI Package Compatibility
The PNG files import directly into common SCADA and HMI platforms. They work in Ignition, Wonderware System Platform, FactoryTalk View SE, WinCC, VTScada, Citect, and simple web based HMI panels. Because PNG is a raster format, there is no need to convert SVG paths or install symbol libraries. You drag the file into your screen editor and size it to the pipe scale.
We recommend the 256 by 256 px size for most mimic screens. Use 512 by 512 px for large overview displays or training slides. Use 64 by 64 px for small pop-up windows and mobile web views. If you need an exact pixel dimension, send us the screen resolution and the pipe line width. We can prepare a custom set.
Typical Applications in Water, Oil and Gas, Chemical, Food, and Marine
The asset pack is used in many process areas. A desalination plant in the Middle East may use electromagnetic flow meter PNG files for seawater intake and brine discharge lines. A chemical plant in Thailand may use Coriolis mass flow meter symbols on a solvent blending HMI. A food and beverage plant in Latin America may show oval gear flow meters on a filling line for edible oil. A marine service company in Singapore may place thermal mass flow meter graphics on a compressed air system mimic.
For each application, the PNG symbol can sit beside the actual field instrument tag. You can label the symbol with a tag number like FIT-2101 and show a live value from a 4-20 mA HART loop. This keeps the HMI close to the real process. It also helps a service engineer find the meter later because the drawing matches the field device style.
How to Get the PNG Asset Pack and a Matching Flow Meter Quote
You can request the asset pack together with a flow meter quotation. Send us your fluid, pipe size in DN, pressure in bar, temperature in degrees Celsius, and flow range in kg/h or m3/h. We will reply with a download link for the PNG pack and a price for the matching instrument. This applies to electromagnetic, Coriolis, ultrasonic, vortex, oval gear, and thermal mass flow meters.
For pricing and technical selection, contact Silver Automation Instruments. Tel: +86-25-68650347. WhatsApp: +86-25-52155837. WeChat: +86 15365082610. You can also visit flow-meter.com.au for the product range.
Frequently Asked Questions About Flow Meter PNG Graphics
Are the PNG files transparent and ready for SCADA use?
Yes. Each file has an alpha channel and no white background. You can place the graphic directly on a dark or light HMI page.
What flow meter types are included in the asset pack?
The pack includes electromagnetic, Coriolis, ultrasonic, vortex, oval gear, and thermal mass flow meters. It also includes pressure transmitter and paperless recorder symbols for panel layouts.
Can I request a custom size or a specific model symbol?
Yes. Send us the required pixel size, screen resolution, and pipe line width. We can prepare a custom PNG set based on the actual Silver Automation Instruments model you plan to use.
Does Silver Automation Instruments supply the actual flow meters shown in the graphics?
Yes. Silver Automation Instruments supplies the full flow meter range. You can receive the PNG graphics for the HMI design and a quotation for the field instruments from the same team.
How do I receive the PNG pack and a flow meter quote?
Send your fluid type, pipe size in DN, pressure in bar, temperature in Celsius, and flow range in kg/h or m3/h. We will reply with the download link and a specific offer.
