1. ANSYS Fluent boundary condition (I): mass flow inlet/outlet The key points for setting the boundary conditions of the mass flow inlet and mass flow outlet in ANSYS Fluent are as follows: mass flow inlet: applicable scenario: mainly applicable to mixed plane models, requiring consideration of the total mass flow of fluid entering the model. Usage restriction: If there are multiple entrances in the model, the total flow of all entrances should be equal to the total flow of all exits, following the principle of conservation of mass. For supersonic fluids or initial gauge pressures, static pressure values must be specified as part of the inlet boundary conditions. Parameter setting: Mass Flow Method: Select Mass Flux with Average Mass Flux to ensure an even distribution of mass within the model. Supersonic/Initial Gauge Pressure: For supersonic fluids or situations based on pressure initialization solutions, static pressure values need to be specified. Mass flow outlet: Applicable scenario: mainly suitable for the outflow boundary of fluids in the model. Usage restrictions: Similar to the mass flow inlet, the principle of conservation of mass must be followed to ensure the balance of total mass flow inside and outside the model. Parameter setting: Quality flow method: Similar to the setting of the quality flow inlet, ensure consistency with the setting of the quality flow inlet. Supersonic/Initial Gauge Pressure: Similarly, for supersonic fluids or specific initial conditions, corresponding static pressure values need to be considered. Summary: When using mass flow inlet and outlet, it is necessary to ensure compliance with the principle of mass conservation and flexibly adjust parameter settings according to actual situations. For supersonic fluids or specific initial conditions, corresponding static pressure values must be specified to ensure the correctness of the models initial state and internal flow. By setting these boundary conditions reasonably, the simulation accuracy and reliability of the simulation results can be effectively improved.

2. ANSYS Fluent Boundary Conditions (Part 1) Mass flow inlet/outlet 3. Numerical simulation software for dynamic processes of surface disasters Massflow
