1. The output current of the frequency converter fluctuates greatly and reports a grounding fault after running for a while. The core reason for the large fluctuation of the output current of the frequency converter and the reporting of a grounding fault is the abnormal grounding current caused by the decrease in insulation of the motor or cable. It is necessary to immediately stop the machine and check the insulation resistance The fault diagnosis steps are to immediately turn off the power and use a megohmmeter (shaking table) to test: - The insulation resistance of the three-phase winding of the motor to ground: The normal value should be greater than 5M Ω (for low voltage motors below 250V) or greater than 10M Ω (for high voltage motors). If it is less than 1M Ω, there is a risk of grounding. - Cable insulation testing: Disconnect the inverter terminal and motor terminal, and measure the phase line to ground resistance separately Common fault points and solutions for motor side problems: - motor winding immersion or insulation aging: drying or rewinding of the coil is required (drying temperature should be controlled at 120 ℃± 10 ℃) - dust accumulation in the junction box deliquescence: drying after cleaning with anhydrous ethanol - bearing damage causing shaft current grounding: replacing insulated bearings (such as SKF 6316/C3VL2071) Cable problems: - armored cable armor tape peeling: replacing shielded cable (shielding layer grounding resistance should be<4 Ω) - joint insulation failure: using cold shrink cable terminal to reseal the frequency converter setting problem: - low grounding fault protection threshold: adjusting parameters (such as Schneider ATV630 GFL code setting value) - high carrier frequency causing capacitive coupling Reduce the carrier frequency to below 4kHz. 3. Emergency solution - if the insulation resistance is between 0.5-1M Between Ω and urgently needed: You can try to enable the grounding fault suppression function of the frequency converter (such as the Earth Fault Management mode of ABB ACS880) - temporarily connect an isolation transformer (with a ratio of 1:1, capacity matching load) to block the grounding circuit - replace with a dedicated frequency converter for four pole grounding detection (such as Danfoss VLT) ® Flow FC 302) 4. Safety warning: Do not force operation when the insulation resistance is less than 0.5M Ω! Possible cause of phase to phase short circuit leading to equipment explosion, grounding current of 380V system can reach over 1000A.

2. How to use a teaching pendant to edit and delete test statements for ABB industrial robots

The method of editing and deleting test statements for ABB industrial robots using a teaching pendant is as follows: Edit test statements: Preparation: Ensure that the ABB industrial robot is correctly installed, debugged, and in teaching mode.
