Arduino Fuel Flow Meter: Prototyping Real-Time Fleet Gasoline Logbooks
Quick Answer: An Arduino fuel flow meter can count pulses from a small sensor and log gasoline volume for a truck, generator, or fuel bowser. For field use, Silver Automation Instruments recommends a metal body oval gear flow meter or a Coriolis mass flow meter with pulse, 4-20 mA, or Modbus output. This setup gives repeatable totals and a fleet logbook that maintenance teams can trust.
Why Fleets Prototype With Arduino First
Fleet managers usually start with an Arduino because a board costs less than 50 USD and the sketch is easy to modify. A common target is a diesel generator, a light truck return line, or a gasoline bowser. The Arduino reads frequency from a flow sensor, converts it to litres per minute, and stores the total on a microSD card or in EEPROM.
In practice, the prototype proves the data flow before a company budgets for an industrial meter. A customer in the Philippines tested this on a 20 kL diesel tank in 2023. The Arduino counted pulses for two days and exposed a refuelling event missing from the paper logbook. That finding was enough to justify a permanent meter.
Typical Sensor Wiring and Signal Limits
Most prototype sensors are plastic Hall-effect turbine devices with a pulse output. Wiring is simple. 5 VDC powers the sensor, ground goes to the Arduino, and the signal pin connects to digital pin 2 or 3 for interrupt counting. The sketch calculates flow from pulse frequency, usually 450 to 550 pulses per litre. Accuracy is around 3 to 5 percent under ideal conditions.
Gasoline is not an ideal fluid. Viscosity near 0.6 cP is low, so small gaps in a plastic rotor cause bypass. Temperature changes alter the meter factor. Petrol vapour can soften plastic bodies. We have seen customer sites where a plastic sensor body failed after two months. Because of this, the Arduino should read a metal body pulse meter, not a low cost water flow sensor.
Matching an Industrial Meter to the Arduino
Silver Automation Instruments offers oval gear flow meters with aluminium or stainless steel bodies for gasoline. A DN15 oval gear meter can measure 2 to 100 litres per hour with repeatability of 0.2 percent. The pulse output still connects to the Arduino digital input, but the pulses are clean and the chamber is metal. This removes the main field failure mode.
For higher accuracy and mass total, we supply Coriolis mass flow meters. A DN10 or DN15 Coriolis meter reports mass flow in kg/h, volume flow, density, and temperature. It can output 4-20 mA HART, pulse, or RS485 Modbus RTU. With 4-20 mA, the Arduino needs a 250 ohm resistor and an analog input. With Modbus, an RS485 TTL converter connects to the serial pins. Most engineers skip Coriolis for small Arduino trials because the price is higher, but it is the right choice when gasoline mass inventory matters.
Do not use an electromagnetic flow meter on gasoline. Fuel is non-conductive, so the signal is too weak or unstable. An oval gear meter or a Coriolis meter is the practical choice for a petrol logbook.
Real-Time Fleet Gasoline Logbooks
A real-time logbook needs three data fields. A meter that counts total volume, a timestamp, and a channel identifier such as truck number or pump number. The Arduino can write a CSV line to a microSD card and a GSM module can push the data to a cloud spreadsheet. Silver Automation Instruments paperless recorders can also collect 4-20 mA signals from multiple meters and store them in a 16 channel log file.
One logistics fleet in Peru used a Silver Automation Instruments oval gear flow meter with pulse output and an Arduino MKR GSM 1400. The system sent a text update every 10 minutes from a fuel bowser in Lima. The fleet supervisor checked the logbook from a phone and stopped two unauthorized fills in the first month. The total cost of the meter was lower than the fuel loss.
Accuracy, Safety, and Compliance Notes
Do not put a plastic flow sensor on petrol or diesel. Use ATEX Zone 1 or Zone 2 rated instruments if the fuel area has a vapour hazard. Silver Automation Instruments can supply flameproof or explosion proof enclosures for pulse output meters. For a fuel depot with truck loading, a DN25 or DN40 oval gear meter with 4-20 mA HART is common. For a generator fuel line with low flow, a DN15 meter works better at start stop conditions.
Send us your pressure in bar, temperature in °C, pipe size in DN, and flow range. We will return a quote with the right meter model, pulse output type, and thread or flange connection. The sales team can also check if your Arduino setup needs a signal isolator.
FAQ
Can an Arduino read a standard industrial flow meter?
Yes. Pulse output and 4-20 mA are the easiest. Use a 5 V signal from a pulse output or a 250 ohm resistor across a 4-20 mA loop. Modbus RTU requires an RS485 converter.
What flow meter type is best for gasoline?
Oval gear meters give good volume accuracy at low and medium flow. Coriolis meters add mass flow and density but cost more. Silver Automation Instruments provides both with pulse, 4-20 mA, and Modbus outputs.
What is the minimum pipe size for a gasoline fuel logbook?
DN15 is common for small engines and generators. DN25 or DN40 covers most fuel bowsers and truck loading skids. Larger terminals may need DN50 or DN80.
Can the meter data go to a cloud dashboard?
Yes. The meter sends pulse or analog data to the Arduino. The Arduino adds a timestamp and pushes a CSV or MQTT message over GSM or Wi-Fi. Silver Automation Instruments paperless recorders can also act as a local backup.
Does Silver Automation Instruments ship to Southeast Asia, Oceania, Latin America, Africa, and the Middle East?
Yes. We supply direct and through distributors. Contact us by Tel: +86-135-1213-1526, Whatsapp: 86-135-12131526, WeChat: +86 13512131526.
Tell us your flow range in litres per hour, pipe size in DN, and whether you need pulse or 4-20 mA output. Silver Automation Instruments will recommend a fuel flow meter that keeps the Arduino logbook stable enough for daily fleet use. You can also check flow-meter.com.au for product datasheets.
