F1210 Flow Meter Data Sheet: Compact Flanged Volumetric Flow Transmitter Calibration
Quick Answer: The F1210 is a compact flanged volumetric flow transmitter for measuring viscous and non-viscous liquids. The data sheet includes calibration limits, pulse output data, K-factor values, flange ratings, and 4-20 mA wiring details. Use this information to specify the right flow meter for fuel, oil, chemicals, or food-grade liquids and to get a fast quote from Silver Automation Instruments.
What Makes the F1210 a Compact Flanged Volumetric Flow Transmitter
The F1210 uses a positive displacement measuring element inside a flanged body. This design delivers direct volume measurement, not velocity-based inference. The compact flanged body supports DN15, DN20, DN25, DN32, DN40, and DN50 process connections. ANSI 150 and DIN PN16 flange patterns are common. Because the body is short face to face, it fits into skids, dosing lines, and fuel test stands where space is limited.
The volumetric flow transmitter section converts rotation of the measuring element into a frequency signal. The data sheet gives the power supply voltage, typically 24 V DC, and the output options. A 4-20 mA loop with HART is available. So is a pulse output with a K-factor in pulses per liter. The F1210 is often used with a batch controller or a PLC input card.
Calibration Data That Engineers Actually Use
Each F1210 arrives with a calibration certificate. The certificate states the serial number, the test fluid, the test temperature, the flow test points, and the resulting K-factor. Silver Automation Instruments tests at minimum three flow points, usually 10 percent, 50 percent, and 100 percent of span. The calibration sheet also shows linearity and repeatability. In practice, repeatability matters more than absolute accuracy for batching resins, inks, and fuels.
Typical accuracy on the F1210 data sheet is plus or minus 0.5 percent of reading for liquids from 5 cP to 1000 cP. Repeatability is plus or minus 0.1 percent. For fluids with viscosity below 5 cP, the meter may need a tighter flow range. For fluids above 1000 cP, pressure drop rises. The calibration sheet helps you avoid that surprise before the meter goes on site.
Flow Transmitter Output and Set Up Steps
The F1210 flow transmitter is a two-wire or three-wire device depending on the output option. Most engineers choose pulse output for simple batching and 4-20 mA HART for continuous monitoring. The K-factor from the calibration sheet is the key number. You enter this pulses-per-liter value into the PLC, flow computer, or batch controller. Then the device gives a volume total that matches the factory test.
Low flow cutoff is another setting from the data s
Applications in Key Markets
Silver Automation Instruments supplies the F1210 to customers in Southeast Asia, the Middle East, Latin America, and Africa. A paint manufacturer in Vietnam uses the F1210 to dose solvent and resin. A chemical distributor in Saudi Arabia uses it for glycol batching. A marine services company in Nigeria uses the F1210 on a fuel transfer skid. In each case the compact flanged body solves a space problem and the calibration data solves the setup problem.
The meter works with diesel, lubricating oil, heavy fuel oil, solvents, molasses, glucose syrup, and some water-based chemicals. The data sheet lists wetted parts. Stainless steel 316L and PEEK gears are common. For food and beverage service, the user should confirm CIP temperature and seal material. Not all F1210 builds are food certified, so specify the fluid contact materials before ordering.
Quote Checklist and Contact Details
To get a price or a PDF data sheet, send your fluid name, flow range, viscosity in cP, pressure in bar, temperature in °C, and pipe size in DN. Also state the output signal: pulse or 4-20 mA HART. Send these details to Silver Automation Instruments. Tel: +86-25-68650347. WhatsApp: +86-25-52155837. WeChat: +86 15365082610.
FAQ: F1210 Flow Meter Data Sheet and Calibration
What does the F1210 calibration certificate include?
It includes the meter serial number, K-factor in pulses per liter, test fluid, test temperature, flow test points, linearity, and repeatability.
Can the F1210 measure low viscosity liquids below 5 cP?
Yes, but the factory may reduce the flow range. Tell Silver Automation Instruments the viscosity and flow range before the order. The calibration sheet then matches the real process condition.
What output signals does the F1210 support?
Pulse output and 4-20 mA HART are standard options. Some versions also support Modbus RTU. Confirm the wiring type with the data sheet before connecting to the PLC.
What flange sizes are available for the F1210?
The compact flanged body covers DN15 to DN50. ANSI 150 and DIN PN16 are common. Other flange ratings may be possible on request.
How often should the F1210 be recalibrated?
For clean lubricating liquids, a 12-month interval is practical. For abrasive or low lubricity fluids, recalibrate every 6 to 9 months or when the repeatability drifts.
